◉ Nanosilica colloidal electrolyte and high tin positive plate alloy design to enhance battery performance
◉Relatively rich electrolyte, high temperature and low temperature performance is superior
◉ Long cycle life, excellent deep cycle discharge ability
◉ Excellent charge acceptance ability
◉ Precision sealing technology
◉ Long life
Model Number :
NUK-6GFM 250GNominal Voltage :
12VNominal Capacity :
250AhBrand :
NuukoSize :
520*268*223mmWeight :
52.0-67.0kg± 3%Container Material :
ABSCountry of Origin :
ChinaNominal Voltage | 12V |
Nominal Capacity | 250Ah |
Design life | 12 years |
Terminal | M8 |
Approx. Weight | Approx 61.0kg |
Container Material | ABS |
Internal resistance | Full charged at 25°C: 3.2 mΩ |
Max. Discharge Current | 3000A(5S) |
Operating Temperature |
Discharge : -40 ~60℃(-40~ 140°F)
Charge : -20 ~50℃(-4~ 122°F)
Storage: -20 ~50℃(-4~ 122°F)
|
Charge Method(25 °C) |
Charge current: Max.62.5A;Recom.25.0 A
Float Charge:13.5-13.8V,recom.13.8V(-18mV/ °C)
Equalize charge:13.8-14.1V,recom.14.1V(-24mV/ °C)
Cycle charge:14.4-15.0V,recom.14.7V(-30mV/ °C)
|
Self discharge | 3 % of capacity declined per month at 25°C |
